Welding fume dust collector, also known as mobile welding fume purifier, is a kind of centralized welding fume purifier. The welding fume dust collector is suitable for arc welding, carbon dioxide shielded welding, MAG welding, carbon arc gouging welding, gas fusion cutting, special welding and other workplaces that generate fume.
Welding fume precipitator, also known as mobile welding fume purifier, is a kind of centralized welding fume purifier. Welding fume precipitator is suitable for arc welding, carbon dioxide shielded welding, MAG welding, carbon arc gouging welding, gas fusion Cutting, special welding and other workplaces that generate smoke.
Equipment introduction
The mobile welding fume dust collector is used for the purification of smoke and dust generated in welding, polishing, cutting, grinding and other processes, as well as the recovery of rare metals and precious materials, etc. It can purify a large number of fine metal particles suspended in the air that are harmful to the human body. It has the characteristics of high p.
urification efficiency, low noise, flexible use, and small footprint.
The welding fume dust collector is suitable for arc welding, carbon dioxide shielded welding, MAG welding, carbon arc gouging welding, gas fusion cutting, special welding and other workplaces that generate fume.
Components
The main components include: universal vacuum arm, high temperature resistant vacuum hose, vacuum hood (with air volume regulating valve), fire retaant net, flame retardant high-efficiency filter element, pulse blowback device, pulse solenoid valve, differential pressure gauge, cleaning chamber, activated carbon filter, ash drawer combination, flame-retardant sound-absorbing cotton, new Korean-style casters with brakes, fan, ABB motor and electric control box, etc.
working principle
Through the gravitational force of the fan, the welding fume is sucked into the air inlet of the equipment through the universal dust suction hood. A flame arrester is installed at the air inlet of the equipment. Coarse dust is directly dropped to the ash hopper, particulate dust is captured on the outer surface by the filter element, the clean air is filtered and purified by the filter element, and then flows into the clean room from the center of the filter element, and the clean air is further purified by the activated carbon filter and then discharged through the air outlet up to standard .
Equipment advantage
1. Equipped with specially imported ABB turbo blower and motor, and adopts an anti-overload circuit to prevent the motor from burning out, with high safety and stable working performance.
2. It adopts built-in centralized PLC control mode, which is simple in structure and easy to operate.
3. Pulse back-blowing automatic dust removal: the filter element adopts all-round automatic rotary back-blowing dust removal, which makes the dust removal on the surface of the filter element more thorough and clean, and can always ensure that the dust collector has a constant suction volume; the air compressor part is a high-pressure rubber hose Connection, high-pressure air intake at the bottom, can ensure that the purifier is always in good working condition. (Automatic or manual control can be designed according to user needs)
4. The filter is made of imported materials from the United States, which has a long service life and can absorb 0.3um dust particles, and has a good filtering effect on wet and sticky dust.
5. Using the universal suction arm that can move freely at 360 degrees, the smoke can be sucked from the place where the smoke occurs, which greatly improves the collection rate of smoke and dust and ensures the health of the workers.
6. The interior of the purifier adopts three protective measures against fire hazards and large particles of slag, which makes the purifier have a longer service life and is safer and more reliable.
7. The clean air is evenly guided and dispersed from the direction of the grille-shaped air outlet, thus reducing the noise to a minimum.
8. It is equipped with special new Korean-style universal casters with brakes, which is convenient for the random movement and positioning of the equipment.
9. Photoelectric control on and off, high efficiency and energy saving, cantilever cover with lighting device (optional).
10. The consumables in the purifier have stable performance and are easy to replace.
Post time: 13-12-22
